IEC53(VCT) | BCC
Attribute:
Flexible cable 300/500V, Copper conductor 2-4 cores
Core :
Diameter :
Categories : Brand , BCC , Products range , VCT ,
Brand : Bangkok Cable
Share
IEC53 BCC
300/500V 70°C FLEXIBLE CONDUCTOR PVC INSULATED AND SHEATHED, ROUND TYPE
Type : VCT IEC53, Flexible copper conductor, PVC insulated
Brand : BCC
Number of Core : Up to 4 cores
Conductor : Flexible coppper conductor, size 1.0 mm² up to 2.5 mm²
Insulation : Polyvinyl chloride (PVC/D) Colour : Natural (Translucent),
Core Identification : 2-Cores; Blue, Brown
3-Cores; Brown, Black, Grey
4-Cores; Blue, Brown, Black, Grey
Shealth : PVC / Colour : Black
Classification : Maximum conductor temperature 70°C. Circuit voltage not exceeding 300/500 Volts
Reference : TIS 11 Part 5-2553
**Prices shown are base prices. Customers can request a discount by these contact channels**
ตารางแสดงราคาตั้ง สายไฟฟ้า (Table of Price List)
| Name and Size (mm²) ชื่อและขนาด (ตร.มม.) | Number of Core จำนวนแกน | ||
| 2 Core(Baht/Meter) 2 แกน(บาท/เมตร) | 3 Core(Baht/Meter) 3 แกน(บาท/เมตร) | 4 Core(Baht/Meter) 4 แกน(บาท/เมตร) | |
| VCT 0.75 mm² | 31.22 | 39.06 | 51.94 |
| VCT 1.0 mm² | 36.54 | 49.56 | 61.74 |
| VCT 1.5 mm² | 48.44 | 61.46 | 79.52 |
| VCT 2.5 mm² | 77.98 | 111.16 | 124.18 |
Products are in the roll of 100 meters
If customers would like to order special length, please contact us by these channels
Tel : 094-325-5151 / 02-8640982-4
Line : @sts7744
Email : sts.thonburi@gmail.com
Facebook : www.facebook.com/ststhonburi
