สายไฟ NYY (single core) | FUHRER
Attribute:
NYY single core, copper conductor with double sheathed. There is resistant to weather conditions and can be buried directly in the ground
Diameter :
Categories : Brand , FUHRER , Products range , NYY ,
Brand : FUHRER
NYY
450/750V 70°C STRANED CONDUCTOR, PVC INSULATED AND DOUBLE SHEATHED
Type : NYY single core, copper conductor, PVC insulated with double sheathed
Brand : FUHRER
Number of Core : 1 cores
Conductor : Solid and stranded annealed copper, Sizes 1 mm² up to 500 mm²
Insulation : Polyvinyl chloride(PVC)
Shealth : Polyvinyl chloride(PVC) Colour : Black
Classification : Maximum conductor temperature 70°C. Circuit voltage not exceeding 750 volts
Testing Voltage : 2,500 Volts
Reference : TIS 11 PART 101-2559
***Prices shown are base prices. Customers can request a discount by these contact channels*
Table of Price List
| Name and Size (mm²) ชื่อและขนาด (ตร.มม.) | Number of Copper (No/mm) จำนวนเส้นลวด (เส้น) | Price (Baht per Meter) ราคา (บาทต่อเมตร) |
| NYY 1x1 mm² | 1 | 31.50 |
| NYY 1x1.5 mm² | 1 | 35.00 |
| NYY 1x2.5 mm² | 1 | 40.88 |
| NYY 1x4 mm² | 1 | 55.16 |
| NYY 1x6 mm² | 7 | 82.32 |
| NYY 1x10 mm² | 7 | 98.70 |
| NYY 1x16 mm² | 7 | 138.32 |
| NYY 1x25 mm² | 7 | 202.44 |
| NYY 1x35 mm² | 19 | 274.40 |
| NYY 1x50 mm² | 19 | 363.58 |
| NYY 1x70 mm² | 19 | 493.92 |
| NYY 1x95 mm² | 19 | 663.60 |
| NYY 1x120 mm² | 37 | 851.20 |
| NYY 1x150 mm² | 37 | 1,044.40 |
| NYY 1x185 mm² | 37 | 1,299.20 |
| NYY 1x240 mm² | 61 | 1,692.60 |
| NYY 1x300 mm² | 61 | 2,109.80 |
| NYY 1x400 mm² | 61 | 2,699.20 |
| NYY 1x500 mm² | 61 | 3,537.80 |
Products are in the roll of 100 meters
If customers would like to order special length, please contact us by these channels.
Tel : 094-325-5151 / 02-8640982-4
Line : @sts7744 (with@)
Email : sts.thonburi@gmail.com
Facebook : www.facebook.com/ststhonburi
